Description

Main – Sensor 640×480 @ 12 um (NETD <40 mK) – Objective lens F50 / 1.0 – Magnification x 3-24 – Field of view (HxV) degrees / m@100m 8.8×6.6 / 15.4×11.5 – Detection range m 2300 – Sensor – Type uncooled – Resolution pixels 640×480 – Pixel pitch um 12 NETD mK 40 – Frame rate Hz 50 – Optics – Objective lens F50 / 1.0 – Magnification x 3-24 – Field of view (HxV) degrees / m @ 100 m 8.8×6.6 / 15.4×11.5 – Eye relief mm 50 – Display – Type AMOLED – Resolution pixels 1024?768 – Range Performance – Detection range m 2300 – Reticle – Click value H/V mm at 100 m 15-3 7.5-6? 3.75-12 1.86-24 – Click range H/V mm at 100 m 3000 / 3000 – Number of preloaded reticles 10 – Video Recorder – Video / photo resolution pixel 1024×768 – Video / photo format .mp4 / .jpg – Built-in memory GB 16 – Wi-Fi – Wireless Protocol Wi-Fi – Wireless Standard IEEE 802.11 b/g/n/ac (WPA) – Frequency GHz 2.4 / 5 – Environmental Characteristics – Degree of protection IP code (IEC60529) IPX7 – Operating temperature range °? -25-+50 – Connections and Compatibilities – Max. recoil power on rifled weapon (Eo) Joules 6000 – Shock resistance on the smooth-bore rifles caliber 12 – Compatible mounts Standard 30 mm rings – Supported Application Stream Vision 2 – Power Supply – Output voltage V 3.7 – Battery type Dual Li-Ion B-Pack Mini Power System: 2 A·h Changeable Battery (external) / 4.9 A·h Battery (internal) – Capacity mAh 2000 (external) + 4900 (internal) – Operating time on battery pack (at t=22°C) h * 9 – External power supply V 5 V 9 V (USB Type-C Power Delivery) – Weight & Size – Body material Aluminum alloy – Dimensions mm 12x78x83 – Weight kg 0.9
